Lithium battery

Overview:

The GP-LFP48V lithium ion phosphate battery system is developed for the backup of Telecom equipment. Under normal condition, the grid AC power supply to rectifier module feeds the telecom loads and charge the battery pack;

When the AC power fails, rectifier module will stop and the telecom equipment is fed from the battery to ensure the Telecom equipment working. When the AC power is recovered, the switch over happens and the rectifier module feed the Telecom equipment and charge the battery pack

Features:

Long cycle life of upto 4000 cycles at 80% DOD.

Quick Recharge capability

  • RS485 communication output for monitoring
  • Built-in BMS with Charging current limitation)
  • Built-in automatic protection for over-charge, over-discharge and over-temperature conditions
  • State of charge and state of health indication
  • Built-in battery control for efficient operation
  • Internal cell balancing
  • Compatible with standard Telecom rectifiers
  • Maintenance free

Model Nominal Capacity Nominal Voltage Nominal Energy Max Discharge Recommended Charge Dimension Approx. Weight
(Ah) (V) (Wh) (A) (A) L(mm) W(mm) T(mm) (Kg)
GP-LFP48V10Ah 10 48 500 10 5 442 285 44 8
GP-LFP48V20Ah 20 48 1000 20 10 442 285 88 14
GP-LFP48V30Ah 30 48 1500 30 10 442 370 88 23
GP-LFP48V40Ah 40 48 2000 40 20 442 430 88 27
GP-LFP48V50Ah 50 48 2500 50 20 442 440 135 31
GP-LFP48V75Ah 75 48 3750 75 30 442 400 177 40
GP-LFP48V100Ah 100 48 5000 75 30 442 520 205 56
Cabinets
VRLA

GreenPole provides batteries of various technologies including but not limited to the following:

  • VRLA batteries (OPzV, AGM and Gel types)
  • Flooded Batteries (OPzS)
  • Lithium Ion batteries
  • Lead Carbon batteries
  • Flow Batteries

Ratings:

  • Voltage: 2V, 6V, 12V and 48V deep cycle batteries
  • Capacity: ranging from 20Ah up to 3000Ah or more by paralleling batteries.

Applications:

  • Deep Cycle
  • Solar
  • Backup
  • Starter

Industry:

  • Telecom
  • Renewable Energy
  • Automotive
  • Traction
  • Marine
  • Military
  • Industrial
